YS-E9679 Android 14 Board

Edge Computing Motherboard

Chip: MTK MT9679

System: Support Android 14 OS

Function: Support 8K display, support 4G LTE

Interface: LVDS / VBYONE / MIC / USB / SPK / Type-C / SIM Card Slot, etc

High Performance Processor

Rich Interface

Support Firmware/Startup Logo Customization

The system runs Android 14, which provides API files

Support the development of upper-layer application

4K Display

Support LVDS 1920 x 1080 resolution

Support VBYONE 4K resolution

Support HD Input 4K

Support 4G LTE

Support 1000M / 100M / 10M adaptive Ethernet

Support WIFI2.4GHz / 5.0GHz

Support 4G / 5G LTE

Support dual-band WIFI 5 / BT 5.0

Application scenarios

Digital signage

Self-service terminal

Advertising machine

Digital Photo Frames

Cashier

YS-E9679 Parameters

CPU

Quad-core Cortex-A73

Main frequency up to 1.4GHz
GPU

Mali G52
APU

Y(1T)
CODEC

Support 4K75, H.265 / AVS3 / VVC / AV1 / HEVC video decoding

Support 1080P60, H.264 video decoding
Display

Support LVDS / VBYONE / HD Input display
Peripheral interface

Support 1000M / 100M / 10M adaptive Ethernet

Support WIFI-2.4G / 5G, BT-5.0

4G module interface

3 x USB 2.0, 2 x USB 3.0, 1 x Type-C

3 x TTL / RS232, 1 x TTL Debug

1 x I2C interface

4 x GPIO port

1 x LVDS interface, up to 1920X1080

1 x VBYONE interface, up to 4K@60Hz

3 x HD Input

1 x Red light

1 x Green light

Support speaker interface, up to one 8Ω 5W dual-channel speaker output

1 x MIC interface

Customized Service

FAQ

Production Capacity

500000PCS/Year
Technical Support

FAE 1 to 1 technical support
OEM/ODM

Firmware customization

Startup logo customization
Warranty Service

3 years warranty 7 days maintenance
Defect Rate 5‰

Guaranteed one-year defect rate

5‰ (after installation)
High-quality PCB

All PCB of the motherboard

Cooperate with listed board factory
